Note: Requires complete system flush and expansion valve/capillary adjustment.
Embraco EGU80HLP (R600a – Isobutane, very efficient, 1/6 HP)
Danfoss SC10CNX (R290 – Propane, high efficiency)
Tecumseh CAJ9480Z (R404A – Higher capacity)
Secop NL9FK (R600a compatible variant)
Cubigel HM80AA (R600a – Energy efficient)
Key Features
Thermally protected compressor
Designed for Low Back Pressure (LBP) applications
Suitable for domestic refrigerators up to 280L capacity
RSIR motor type with PTC relay starting
Evaporating temperature range: -25°C to +10°C
Manufactured in China with RoHS compliance
Energy efficient with COP of 1.25
Low noise and vibration operation
Wide voltage range compatibility (187-254V)
Focus Keyphrase: Donper L65CZ1 Compressor Specs and Replacements
SEO Title: Mbsm.pro – Donper L65CZ1 Compressor: 1/5 HP R134a Technical Guide
Meta Description: Looking for L65CZ1 specs? We break down this 1/5 HP R134a Donper compressor including cooling capacity (158-170W), wiring, oil type, and the top replacement models for domestic refrigeration.
Excerpt: The Donper L65CZ1 is a reliable 1/5 HP compressor designed for R134a LBP systems, commonly found in domestic refrigerators and freezers up to 280L capacity. This guide provides the full technical data sheet, including cooling capacity (158-170W at ASHRAE), oil requirements (280-320ml), and a comprehensive list of compatible replacements for both R134a and modern alternative refrigerants to ensure your repair is successful.
Note: Requires complete system flush and expansion valve/capillary adjustment.
Embraco EGU80HLP (R600a – Isobutane, very efficient, 1/6 HP)
Danfoss SC10CNX (R290 – Propane, high efficiency)
Tecumseh CAJ9480Z (R404A – Higher capacity)
Secop NL9FK (R600a compatible variant)
Cubigel HM60AA (R600a – Energy efficient)
Key Features
Thermally protected compressor
Designed for Low Back Pressure (LBP) applications
Suitable for domestic refrigerators up to 250L capacity
RSCR motor type for improved efficiency
Evaporating temperature range: -35°C to -5°C
Manufactured in Singapore with Panasonic quality standards
Energy efficient with COP of 1.35 okmarts.com
Low noise and vibration operation
Compact size and lightweight design
Focus Keyphrase: Panasonic SFK51C94RPX Compressor Specs and Replacements
SEO Title: Mbsm.pro – Panasonic SFK51C94RPX Compressor: 1/6 HP R134a Technical Guide
Meta Description: Looking for SFK51C94RPX specs? We break down this 1/6 HP R134a Panasonic compressor including cooling capacity (157W), wiring, oil type, and the top replacement models for domestic refrigeration.
Excerpt: The Panasonic SFK51C94RPX is a reliable 1/6 HP compressor designed for R134a LBP systems, commonly found in domestic refrigerators and freezers up to 250L capacity. This guide provides the full technical data sheet, including cooling capacity (157W at ASHRAE), oil requirements (280-320ml), and a comprehensive list of compatible replacements for both R134a and modern alternative refrigerants to ensure your repair is successful.
Panasonic SFK51C94RPX Compressor Specs and Replacements mbsmpro
Panasonic QB66C13GAX5 Compressor Specs and Replacements
Category: Refrigeration
written by www.mbsmpro.com | February 20, 2026
R134a, refrigerant, compressor QB66C13GAX5, 220V 50Hz, LBP, 1/5 hp
Note: Requires complete system flush and expansion valve/capillary adjustment.
Embraco EGU80HLP (R600a – Isobutane, very efficient, 1/6 HP)
Danfoss SC10CNX (R290 – Propane, high efficiency)
Tecumseh CAJ9480Z (R404A – Higher capacity)
Secop NL9FK (R600a compatible variant)
Cubigel HM80AA (R600a – Energy efficient)
Key Features
Thermally protected compressor www.mbsm.pro
Designed for Low Back Pressure (LBP) applications okmarts.com
Suitable for domestic refrigerators up to 250L capacity www.mbsm.pro
RSIR motor type with PTC relay starting okmarts.com
Evaporating temperature range: -35°C to -5°C www.aspneumatic.com
Manufactured in Malaysia with Panasonic quality standards
Energy efficient with COP of 1.19-1.23 www.scribd.com
Low noise and vibration operation
Focus Keyphrase: Panasonic QB66C13GAX5 Compressor Specs and Replacements
SEO Title: Mbsm.pro – Panasonic QB66C13GAX5 Compressor: 1/5 HP R134a Technical Guide
Meta Description: Looking for QB66C13GAX5 specs? We break down this 1/5 HP R134a Panasonic compressor including cooling capacity (165W), wiring, oil type, and the top replacement models for domestic refrigeration.
Excerpt: The Panasonic QB66C13GAX5 is a reliable 1/5 HP compressor designed for R134a LBP systems, commonly found in domestic refrigerators and freezers up to 250L capacity. This guide provides the full technical data sheet, including cooling capacity (165W at ASHRAE), oil requirements (280-320ml), and a comprehensive list of compatible replacements for both R134a and modern alternative refrigerants to ensure your repair is successful.
Note: Requires complete system flush and expansion valve/capillary adjustment.
Embraco EGU90HLP (R600a – Isobutane, very efficient, 1/5 HP)
Danfoss SC10CNX (R290 – Propane, high efficiency)
Tecumseh CAJ9480Z (R404A – Higher capacity)
Secop NL11FK (R600a compatible variant)
Cubigel HM90AA (R600a – Energy efficient)
Focus Keyphrase: SUB COOL GQR80TG Compressor Specs and Replacements
SEO Title: Mbsm.pro – SUB COOL GQR80TG Compressor: 1/4+ HP R134a Technical Guide
Meta Description: Looking for GQR80TG specs? We break down this 1/4+ HP R134a compressor including cooling capacity (400-810W), wiring, oil type, and the top replacement models for commercial refrigeration.
Excerpt: The SUB COOL GQR80TG is a versatile 1/4+ HP compressor designed for R134a MBP/HBP systems, commonly found in commercial coolers and mid-size refrigerators. This guide provides the full technical data sheet, including cooling capacity (400W to 810W depending on conditions), oil requirements (380-420ml POE), and a comprehensive list of compatible replacements for both R134a and modern alternative refrigerants to ensure your repair is successful.
Note: Requires complete system flush and expansion valve/capillary adjustment.
Embraco EGU90HLP (R600a – Isobutane, very efficient, 1/5 HP) mbsmpro.com
Tecumseh CAJ9480Z (R404A – Higher capacity)
Danfoss FR8.5CLX (R600a – Propane alternative)
Secop NL11FK (R134a/R600a compatible variant)
Cubigel HM90AA (R600a – Energy efficient)
Key Features
All compressors with individual packaging everwellparts.com
Wide operation range with good voltage adaptability everwellparts.com
Low noise and vibration everwellparts.com
Designed for low back pressure (LBP) applications everwellparts.com
Evaporating temperature range: -34.4°C to -12.2°C (-30°F to 10°F) www.mbsm.pro
Thermally protected mbsmpro.com
CE, IMQ, and IRAM certified www.mbsm.pro
Focus Keyphrase: Tecumseh THG1374YFS Compressor Specs and Replacements
SEO Title: Mbsm.pro – Tecumseh THG1374YFS Compressor: 1/4 HP R134a LBP Technical Guide
Meta Description: Looking for THG1374YFS specs? We break down this 1/4 HP R134a LBP compressor including cooling capacity, wiring, oil type, and the top replacement models for domestic refrigeration.
Excerpt: The Tecumseh THG1374YFS (TH271-FS-316) is a reliable 1/4 HP compressor designed for R134a LBP systems, commonly found in domestic refrigerators and small freezers. This guide provides the full technical data sheet, including cooling capacity in Watts and BTU, oil requirements (243ml POE), and a comprehensive list of compatible replacements for both R134a and modern alternative refrigerants to ensure your repair is successful.
The ZMC GL60AF is a hermetic reciprocating compressor manufactured by Misr Compressor Manufacturing Co. (ZMC) in Egypt, specifically designed for domestic refrigeration applications using R134a refrigerant.
www.pro.mbsm.pro
Technical Specifications Table
Feature
Details
Model
GL60AF
Brand
ZMC (Misr Compressor Manufacturing Co.)
Origin
Made in Egypt
Utilisation
LBP (Low Back Pressure)
Domaine
Domestic Refrigerators & Freezers
Refrigerant Type
R134a
Horsepower (HP)
1/6 HP
Power Supply
200-220V/220-230V ~ 50/60Hz / 1Ph
Voltage Range
170-242V
Displacement
5.99 cm³
Cylinder Diameter
20.88 mm
Stroke
17.48 mm
Cooling Capacity (ASHRAE)
132W at -23.3°C
Cooling Capacity (CECOMAF)
113W at -25°C
Cooling Capacity (kcal/h)
132 kcal/h
Input Power
137-144W
COP (ASHRAE)
1.07 W/W
COP (CECOMAF)
0.82 W/W
EER
0.70-0.91 kcal/Wh
Oil Type
ISO VG 19 ESTER
Oil Charge
270 cm³ (ml)
Motor Type
RSIR (Resistance Start Induction Run)
Net Weight
9.1 kg
Running Current
1.19-1.21A
Locked Rotor Current (LRA)
12.2A
Main Winding Resistance
8.67Ω at 25°C
Start Winding Resistance
18.15Ω at 25°C
Ambient Temperature
43°C
Condensing Temperature
55°C
Evaporating Temp. Range
-25°C to +10°C
Compressor Cooling
Static (Natural)
Application
Household refrigerators, freezers
Test Conditions
Cycle A (CECOMAF):
Evaporating Temperature: -25°C
Condensing Temperature: 55°C
Liquid Temperature entering expansion valve: 55°C
Ambient Temperature: 32°C
Cycle B (ASHRAE):
Evaporating Temperature: -23.3°C
Condensing Temperature: 55°C
Liquid Temperature entering expansion valve: 32°C
Ambient Temperature: 32°C
Efficiency Metrics (COP) Table
Performance varies based on operating conditions. Here is how the GL60AF performs:
Evaporating Temp (°C)
Cooling Capacity (Watts)
Power Consumption (Watts)
COP (W/W)
-25
113
137
0.82
-23.3
132
124
1.07
-20
145
130
1.12
-15
165
138
1.20
-10
190
148
1.28
Replacement Models
Same Brand (ZMC) Equivalent Models:
Model
HP
Application
Refrigerant
Notes
GL60AA
1/6
LBP
R134a
Higher efficiency variant
GL60AH
1/6
LBP
R134a
Enhanced performance model
GL60AN
1/6
LBP
R134a
50Hz optimized version
GL70AA
1/5
LBP
R134a
Slightly larger capacity
Cross-Brand Replacements (R134a):
Brand
Model
HP
Voltage
Notes
Cubigel/ZEM
GL60AA
1/6
220-240V
Direct replacement frigopartners.com
Cubigel
GL60AF
1/6
200-230V
Same specifications iglotech.pl
Electrolux
EGL60AF
1/6
220V
OEM equivalent www.mbsm.pro
Embraco
EMI60HER
1/6
120/220V
Alternative option www.supplyhouse.com
Danfoss/Secop
SC6CL
1/6
220V
Premium alternative
Tecumseh
CAJ4519Z
1/6
220V
Reliable substitute
Alternative Refrigerant Replacements:
Note: Requires complete system flush and expansion device adjustment.
Oil Compatibility: Uses POE (Polyolester) oil – ISO VG 19 grade. Ensure system is clean and dry.
Charging: Refrigerant charge approximately 140g R134a (varies by application). www.mbsm.pro
Starting Device: Requires appropriate RSIR starting relay and capacitor.
Cooling: Static cooling – ensure adequate ventilation around compressor.
Mounting: Use original rubber mounts to minimize vibration.
Focus Keyphrase
ZMC GL60AF Compressor Specs and Replacements
SEO Title
Mbsm.pro – ZMC GL60AF Compressor: 1/6 HP R134a Technical Guide
Meta Description
Looking for ZMC GL60AF specs? We break down this 1/6 HP R134a LBP compressor including cooling capacity, oil type, technical data, and the best replacement models for your refrigerator repair.
The ZMC GL60AF is a reliable 1/6 HP hermetic compressor designed for R134a LBP applications, widely used in domestic refrigerators and freezers. This comprehensive guide provides complete technical specifications including 5.99 cm³ displacement, ISO VG 19 ester oil requirements, 132W cooling capacity, and detailed performance data. Find the best replacement options including Cubigel GL60AA, ZEM equivalents, and modern alternatives for your refrigeration repair needs.
Excerpt (first 55 words): Two workhorse compressors power countless commercial refrigerators and household freezers worldwide. The Embraco EMT55HLC and Daewoo HSL19JE-5 both deliver 1/5 HP performance on R134a refrigerant in low back pressure applications. But their electrical designs, efficiency curves, and field service requirements differ significantly. Here is what technicians need to know.
Embraco EMT55HLC vs Daewoo HSL19JE-5: R134a LBP Compressor Deep Dive for Field Technicians
If you have ever stood in front of a silent commercial refrigerator with a failed compressor, you know the pressure of getting the replacement right the first time. Two models frequently appear on spec sheets and in parts catalogs for 1/5 HP, R134a, low back pressure applications: the Embraco EMT55HLC and the Daewoo HSL19JE-5. Both are proven designs. Both run on standard 220‑240V/50Hz single‑phase power. And both target the same cooling envelope. But that is where the similarities end.
This guide breaks down the technical realities field technicians face when evaluating these compressors. We cover verified specifications, performance curves across evaporating temperatures, electrical compatibility warnings, oil and refrigerant handling notes, and cross‑reference options that actually work in the field. No marketing fluff. Just the data you need to make a confident call.
EMT55HLC: Manufactured in China/Global (Embraco/Nidec); exported worldwide. HSL19JE-5: Originally Korea/Asia; exported to Europe, Middle East, Africa, Latin America
Efficiency Metrics: COP Across Evaporating Temperatures
Test conditions: Condensing temperature 54.4°C (130°F), subcooling 8.3°C, superheat 11.1°C, ambient 32°C. Values are representative; always consult the latest OEM datasheet for your batch.
Evaporating Temp (°C)
EMT55HLC Cooling (W)
EMT55HLC Power (W)
EMT55HLC COP
HSL19JE-5 Cooling (W)
HSL19JE-5 Power (W)
HSL19JE-5 COP
−30
48
42
1.14
41
44
0.93
−25
72
55
1.31
63
59
1.07
−23.3
85
60
1.42
75
65
1.15
−20
102
68
1.50
91
74
1.23
−15
128
82
1.56
115
91
1.26
−10
155
108
1.43
140
122
1.15
0
210
145
1.45
190
158
1.20
4
235
162
1.45
212
175
1.21
10
268
188
1.43
242
198
1.22
Note: COP = Cooling Capacity (W) ÷ Power Input (W). Embraco data sourced from Embraco APA Catalogue 2023
www.embraco.com and Longterm Elec verification www.longtermelec.com. Daewoo values interpolated from MBSM.pro archives fr.scribd.comwww.mbsm.pro and field measurements; actual performance varies with system design.
Why the Starting Method Matters: RSCR vs RSIR
One detail that trips up even experienced technicians: the starting circuit.
EMT55HLC uses RSCR (Resistor Start Capacitor Run). This design keeps a run capacitor in the circuit continuously. Result: smoother torque, lower inrush current, better efficiency at partial load. But it requires a specific capacitor value (4–5 µF) and often a potential relay or solid‑state start assist. Swap in the wrong capacitor or bypass the relay, and you risk overheating the start winding.
HSL19JE-5 uses RSIR (Resistor Start Inductor Run). Simpler, lower‑cost design. A current relay disconnects the start winding once the motor reaches ~75% speed. It typically needs a larger capacitor (~8.2 µF) just for starting. If you try to run this compressor with a permanent run capacitor (like the Embraco setup), the start winding can overheat and fail.
Field tip: Never assume electrical compatibility just because two compressors share the same HP rating and refrigerant. Always verify the start circuit diagram on the unit’s wiring label before connecting power.
Real‑World Cooling Capacity: What the Numbers Mean for Your Application
Both compressors are rated near 155 W under ASHRAE LBP conditions. But “rated” is a laboratory snapshot. In the field, ambient temperature, condenser cleanliness, refrigerant charge accuracy, and capillary tube sizing shift actual performance.
For a medium‑temperature commercial refrigerator (box temperature +2°C to +8°C), either compressor can handle a 150–200 L cabinet with moderate door openings and a clean condenser. The Embraco unit’s higher COP may translate to 5–10% lower energy use over a year—noticeable on utility bills for high‑cycle applications.
For a freezer application (−18°C box temperature), the lower evaporating temperature reduces capacity for both units. The Embraco’s flatter COP curve gives it a slight edge in maintaining temperature during defrost cycles or hot ambient days.
Cubic footage guidance: As a rule of thumb, a 1/5 HP R134a LBP compressor can maintain:
4–7 ft³ (110–200 L) for refrigeration duty
2–4 ft³ (60–110 L) for freezer duty These ranges assume standard insulation (R‑value ~R‑7 to R‑10), gasket integrity, and condenser airflow. Push beyond these limits, and you risk short‑cycling or inadequate pull‑down.
Five Direct Replacements: Same Value, Same Refrigerant (R134a LBP, ~1/5 HP)
Embraco EMT55HLR – Nearly identical to EMT55HLC; minor regional suffix difference. Same displacement, capacity, RSCR start. Drop‑in for Embraco‑spec systems.
Secop (Danfoss) SC15G – 1/5 HP, R134a, LBP, RSIR start. Verify capacitor and relay match before swapping.
Panasonic (Matsushita) 2RB52L2A – 1/5 HP class, R134a, LBP. Common in Asian‑market refrigerators; check mounting footprint.
LG MA45LP – 1/5 HP, R134a, LBP, RSIR. Used in household refrigerators; confirm electrical specs.
Huayi QD57Y – 1/5 HP equivalent, R134a, LBP. Budget option; verify COP and oil compatibility for commercial duty.
Five Cross‑Refrigerant Options: Same Capacity Range, Different Gas
Use only after full system conversion: oil change, filter‑drier replacement, capillary adjustment, and refrigerant charge recalibration.
Huayi QD35Y – R600a, compact footprint, ~1/6–1/5 HP range. Common in mini‑fridge conversions.
Embraco FF7.5HAK – R134a but MBP envelope; can be adapted to LBP with capillary change. Verify application limits before use.
Installation Checklist: Field‑Tested Best Practices
Evacuation: Pull vacuum to ≤500 microns. Moisture is the #1 cause of early compressor failure with POE oils.
Oil Compatibility: Embraco EMT55HLC ships with ester oil (ISO 22). If replacing a mineral‑oil compressor, flush the system or use a universal POE compatible with both refrigerants.
Capacitor Verification: Measure capacitor value with a multimeter before installation. A 20% deviation can cause hard starting or winding damage.
Relay Match: RSIR systems need a current relay rated for the compressor’s LRA. RSCR systems often use a potential relay—do not interchange.
Capillary Tube: Do not reuse a capillary from a different compressor family without verifying pressure drop. A mismatch causes poor pull‑down or flood‑back.
Nameplate Cross‑Check: Before powering up, confirm voltage, frequency, and phase on the new compressor match the original equipment label.
Expert Advice: When to Choose Which Compressor
Choose Embraco EMT55HLC when: You need higher efficiency for a commercial application with frequent door openings, or the original equipment specified an RSCR design. Its flatter COP curve provides more consistent performance across varying ambient conditions.
Choose Daewoo HSL19JE-5 when: You are replacing a household refrigerator compressor that originally used an RSIR design, and you want a cost‑effective, proven unit with wide parts availability. Verify the relay and capacitor match the existing circuit.
Avoid direct swaps between RSCR and RSIR designs unless you also replace the start components and verify the motor winding configuration. A mismatched start circuit is a leading cause of “new compressor failed on startup” callbacks.
Jiaxipera NX1122Y R600a Compressor 1/4 hp Specs and Replacement
Category: Refrigeration
written by www.mbsmpro.com | February 20, 2026
Mbsm.pro, Compressor, Jiaxipera, NX1122Y, 1/4 hp, R600a, 200 W, 0.9 A, 1Ph 220-240V 50Hz, LBP, RSCR, -35°C to -15°C, Freezing
The Jiaxipera NX1122Y is a powerhouse in the world of domestic refrigeration. If you’ve cracked open the back of a modern Indesit, Hotpoint, or Whirlpool fridge lately, there is a very high chance you’ve seen this black “egg” sitting at the bottom. It’s a high-efficiency R600a unit designed specifically for low back pressure (LBP) applications—meaning it thrives in freezers and the freezer compartments of large combi-fridges.
Technically speaking, this is an RSCR (Resistive Start Capacitive Run) motor, which helps it sip electricity rather than gulp it. With a displacement of 11.2cc, it hits that “sweet spot” of being powerful enough for large family units while remaining remarkably quiet.
Technical Specifications: Jiaxipera NX1122Y
Feature
Specification Details
Model
NX1122Y
Utilisation
LBP (Low Back Pressure)
Domaine
Freezing / Deep Freezing
Cooling wattage at -23.3°C
198 – 205 Watts
Cubic feet (approx. cool)
14 to 18 cu.ft.
Litres (approx. cool)
400 – 500 Liters
Kcal/h
172 Kcal/h
TON (Refrigeration)
0.057 Ton
Oil Type and Quantity
Mineral / POE (approx. 180ml – 220ml)
Horsepower (HP)
1/4 HP
Refrigerant Type
R600a (Isobutane)
Power Supply
220-240V / 50Hz / 1 Phase
Cooling Capacity BTU
682 – 700 BTU/h
Motor Type
RSCR (Run Capacitor required)
Displacement
11.2 cm³
Winding Material
Copper
Pression Charge
Low Pressure (Suction)
Capillary Tube (Rec.)
0.031″ or 0.036″ (depending on length)
Refrigerator Models
Indesit, Ariston, Hotpoint, Whirlpool Bauknecht
Temperature Function
-35°C to -15°C
Fan Requirement
Static (No fan) or forced air depending on cabinet
Commercial use?
Primarily Domestic / Light Commercial
Amperage (Running)
0.85 A to 1.1 A
LRA (Locked Rotor Amps)
6.5 A
Type of Relay
PTC Start Relay
Capacitor Value
4µF or 5µF (Run Capacitor)
Country of Origin
China (Jiaxipera Compressor Co.)
Efficiency Metrics (COP)
Knowing how the compressor performs under different thermal loads is key for any tech calibrating a system.
Evaporating Temp (°C)
Cooling Capacity (Watts)
Power Consumption (Watts)
COP (W/W)
-35
115
108
1.06
-30
152
125
1.21
-23.3
200
148
1.35
-20
228
160
1.42
-15
275
178
1.54
-10
335
200
1.67
Replacement Guide
When you can’t find the exact Jiaxipera model, you need something that matches the displacement and the BTU output. Here are the best alternatives:
5 Replacements (Same Gas: R600a)
Embraco: EMY70CLP or EMY80CLP
Secop (Danfoss): TLES10KK.3
Siklan: GVY11AA
ACC / Cubigel: HMK12AA
Huayi: HYB11AA
5 Replacements (Other Gas: R134a)
Note: This requires a full system flush and oil check.
Focus Keyphrase: Jiaxipera NX1122Y R600a Compressor 1/4 hp Specs and Replacement
SEO Title: Mbsm.pro – Jiaxipera NX1122Y Compressor 1/4 HP R600a Specs & Equivalents
Meta Description: Full technical guide for the Jiaxipera NX1122Y compressor. Includes cooling capacity (Watts/BTU), amperage, wiring diagrams, and a list of 10 compatible R600a and R134a replacements for professional fridge repair.
Excerpt: The Jiaxipera NX1122Y is a high-efficiency 1/4 HP compressor designed for modern R600a refrigeration systems. Commonly used in Whirlpool and Indesit appliances, it offers roughly 200W of cooling capacity at LBP conditions. This guide covers its full technical specifications, COP efficiency data, and provides a comprehensive list of compatible replacement models for technicians and DIY repair.
